All-city thunderdome bike 700c aluminum gold fang
All-city thunderdome bike 700c aluminum gold fang
All-city thunderdome bike 700c aluminum gold fang
All-city thunderdome bike 700c aluminum gold fang
All-city thunderdome bike 700c aluminum gold fang
In Stock

All-City Thunderdome Bike 700c Aluminum Gold Fang

Free Shipping, 4 Sizes

$1,599.00

This product is shipped only in the U.S.
  • Model: Thunderdome Bike – Gold Fang
  • Brand: All-City
  • Imported
  • Free Shipping
Stock availability can be changed at any time
SKU: N/A Categories: , , , Tags: , ,

Description

All-City Thunderdome Bike 700c Aluminum Gold Fang

Drilled for front and rear brakes and quicker than ever, the All-City Thunderdome is crafted from our proprietary blend of race-ready Alumisonic aluminum tubes. Lightweight and responsive, this UCI-certified sprinter has proven itself on the boards of velodromes across the globe. On the track or on the city streets, its one and only speed is fast.

  • UCI-certified track bike
  • Classic round-profile tubing constructed from Alumisonic aluminum
  • Replaceable stainless steel axle pads
  • Tapered head tube and tapered steerer carbon fork
  • Signature Shot Collar seat post clamp
  • Tire clearance: 700 x 25c
  • Fork Material: Carbon
  • Color: Gold Fang
  • Wheel Size: 700c
  • Brake Type: Rim
  • Platform: Thunderdome
  • Fork Type: Rigid
  • Rear Axle: 10×1 Threaded x 120mm
  • Frame Material: Aluminum
  • TT (Effective): 510
  • Defined Color: Black
  • Mfg Size: 46
  • Front Axle: QR x 100mm
  • Frame Type: Rigid

Prop65warning 6pt WARNING Handling this product will expose you to chemicals, including lead, known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. For further information go to www.P65Warnings.ca.gov.​

All-City Thunderdome Bike 700c Aluminum Gold Fang

Frameset

Frame: All-City Alumasonic, TIG Welded

Fork: Whisky No.7 RD Tapered

Seatclamp: All-City Shot Collar, 31.8mm

Drivetrain

Crankset: All-City 612 Track Crank, 165mm, 49t ring

Bottom Bracket: Square Taper, 68 x 110mm steel cups, sealed bearings

Front Derailleur: N/A

Rear Derailleur: N/A

Cassette / Cog: All-City standard, 17t

Chain: KMC B1H-Wide

Components

Headset: Cane Creek 40 Series

Brakes: Tektro R326

Brake Levers: Tektro RL340

Shifters: N/A

Stem: Whisky No.7

Handlebar: Whisky No.7

Grip/Tape: All-City Super-Cush w/ Locking Alloy All-City End Plugs

Saddle: Black Saddle

Seatpost: Whisky No.7

Wheels

Front Hub: JoyTech A565, 32h

Rear Hub: JoyTech A566, 32h

Rims: Alex AT505, 32h, with CNC Brake Track

Tires: Donnelly Strada LGG, 700×25, 60tpi

Tubes: included

Other

Pedals: N/A

Misc: –

* Specifications are subject to change without notice

GEOMETRY

bike geometry

Frame measurements (mm) 46cm 49cm 52cm 55cm 58cm 61cm
A. BB Drop 53 53 53 53 53 53
B. Chainstay Length 396 396 396 396 396 396
C. Fork Length – Axle to Crown 367 367 367 367 367 367
D. Fork Offset 45 45 45 45 45 45
E. Head Tube Angle (deg) 72 72.5 72.5 72.5 72.5 72.5
F. Headtube Length 113 128 148 168 193 218
G. Reach 378 384 394 403 417 430
H. Seat Tube Angle (deg) 75 75 74.5 74.5 74.5 74.5
I. Seat Tube Length – Center to Top 460 490 520 550 580 610
J. Stack 493 509 528 547 571 595
K. Standover 742 766 791 816 843 870
L. Top Tube Length (Effective) 510 520 540 555 575 595
M. Wheelbase 961 967 983 999 1020 1041
Component measurements (mm)
Crank Arm Length 165 165 165 165 165 165
Handlebar Width 380 400 420 420 440 440
Seatpost Offset 0 0 0 0 0 0
Stem Length 90 90 100 100 110 120
Stem Angle (deg) 7 7 7 7 7 7

Additional information

Categories

Brand

Color

Size

46cm, 49cm, 52cm, 55cm
