All-City Gorilla Monsoon Bike 650b Steel APEX Tangerine Evergreen

Free Shipping, 7 Sizes

$2,199.00

This product is shipped only in the U.S.
  • Model: Gorilla Monsoon Apex Bike – Tangerine Evergreen
  • Brand: All-City
  • Imported
  • Free Shipping
Stock availability can be changed at any time

Description

All-City Gorilla Monsoon Bike 650b Steel APEX Tangerine Evergreen

Designed to handle double track, gravel, bike camping, and just plain chasing good times, this nimble, do-it-all dirt solution is ready to send cross racers, dirt tourists, and backcountry explorers far into the unknown with comfort, style, and elegance. Available in seven frame sizes — including 43cm for the first time — the Gorilla Monsoon is tweaked for long days in the saddle and built around 27.5 x 2.4″ tires with clearance for 700c x 42mm.

  • Made from All-City’s 612 Select steel tubing with signature thru-axle dropouts
  • Features a matching bi-plane crown steel fork
  • Fork is compatible with Surly 8- and 24-Pack racks
  • Mounts for front and rear racks and fenders
  • Flat-mount disc brakes
  • Three water bottle mounts on the frame
  • Dropper seatpost
  • Signature All-City Shot Collar seatpost clamp
  • E.D. coated for durability and rust prevention
  • Fork Material: Steel
  • Color: Tangerine Evergreen
  • Wheel Size: 650b
  • Brake Type: Disc
  • Platform: Gorilla Monsoon
  • Fork Type: Rigid
  • Rear Axle: 12mm Thru x 142mm
  • Frame Material: Steel
  • TT (Effective): 505
  • Defined Color: Multi-Color
  • Mfg Size: 43
  • Front Axle: 12mm Thru x 100mm
  • Frame Type: Rigid
Prop65warning 6pt WARNING Handling this product will expose you to chemicals, including lead, known to the State of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. For further information go to www.P65Warnings.ca.gov
Just ArrivedFlat Rate Shipping

All-City Gorilla Monsoon Bike 650b Steel APEX Tangerine Evergreen

Frameset

Frame: 612 Select Chromoly Steel, TIG Welded and Brazed, E.D. Coated

Fork: 612 Select Chromoly Steel, All-City Signature fork ends, Bi-Wing Crown, TIG Welded and Brazed, E.D. Coated

Drivetrain

Crankset: FSA Comet V-Drive 38t, MegaEXO

Bottom Bracket: FSA BB7100

Front Derailleur: N/A

Rear Derailleur: SRAM Apex

Cassette: SunRace CSMS8 11-speed, 11-42t

Chain: KMC X11 EPT

Components

Grips / Bar Tape: All-City Embossed Black Tape

Handlebar: JD RA48A

Stem: JD ST123A, 31.8mm, ±7° Rise

Headset: Cane Creek 40 Series

Shifter: SRAM Apex

Brake Levers: SRAM Apex

Brakes: Tektro MD-C550

Rotors: Tektro TR160-22 160mm F/R 6-Bolt

Saddle: All-City Gonzo

Seatpost: TranzX JD-TSI01L, 27.2, 350mm L, 50mm drop

Wheels

Front Hub: Novatec D981SB 12×100 32h

Rear Hub: Novatec D982TSB 12×142 32h

Rims: WTB ST i25 TCS 2.0, 32h

Tires: WTB Riddler, 27.5 x 2.4″, TCS Light/Fast

Tubes: included/installed

Other

Pedals: N/A

Misc: –

* Specifications are subject to change without notice

GEOMETRY

bike geometry

Frame measurements (mm) 43cm 46cm 49cm 52cm 55cm 58cm 61cm
A. BB Drop 62.5 62.5 62.5 62.5 62.5 62.5 62.5
B. Chainstay Length 430 430 430 430 430 430 430
C. Fork Length – Axle to Crown 395 395 395 395 395 395 395
D. Fork Offset 50 50 50 47 47 47 47
E. Head Tube Angle (deg) 70 71 71 71.5 71.5 71.5 71.5
F. Headtube Length 115 125 135 155 175 200 225
G. Reach 357 363 368 374 382 389 402
H. Seat Tube Angle (deg) 74.5 74 74 73.5 73 72.5 72.5
I. Seat Tube Length – Center to Top 415 445 475 510 540 570 600
J. Stack 534 547 557 579 598 622 645
K. Standover 711 735.5 758.2 788.3 813.4 840.1 866.8
L. Top Tube Length (Effective) 505 520 528 545 565 585 605
M. Wheelbase 1007 1008 1017 1021 1036 1051 1072
Component measurements (mm)
Crank Arm Length 165 165 170 170 170 175 175
Handlebar Width 400 400 420 440 440 460 460
Stem Length 70 80 90 100 100 110 120

* All dimensions are preliminary and subject to change
